Sentinel VPT
NEMA 4, 4x, 7, 9 for Explosion-Proof Applications
The Sentinel VPT has been designed to provide the most visible and reliable valve position indication in explosion-proof environments. With a wide variety of switches and sensors available to match your application, the Sentinel is the perfect choice.
Design Features
- UL and CSA Certified for Explosion-proof.
- Patented Engineered Loc-Ring Cam and Shaft Retention System provides unsurpassed sensing accuracy over the multi-million cycle life of the physical platform.
- Clear Ektar cover offers optimum chemical resistance and strength and is environmentally sealed to prevent fogging or entry of contaminants.
- Careful material selection provides patented indicator a rated life of minimum 1,000,000 cycles.
- Materials of construction selected to excel in high vibration, corrosive and dirty environments, either indoors or outdoors.
- Indicator is fully adjustable to any valve or actuator.
- Internal Switches and terminal block are labeled for easier installation.
- The industry's only "true" visual valve position indicator available for multi-port valves, adjustable to match the actual physical flow pattern of the valve.
- "Flat cover" version is available without an indicator for areas with tight space requirements.
- See datasheet for additional details.
Watchman VPT
NEMA 4, 4x for General Purpose Applications
The Watchman VPT has been designed to provide the most visible and reliable valve position indication in general purpose applications. With a wide variety of switches and sensors available to match your application, the Watchman is the best choice.
Design Features
- CSA Certified for General Purpose applications
- Patented Engineered Loc-Ring Cam and Shaft Retention System provides unsurpassed sensing accuracy over the multi-million cycle life of the physical platform.
- Clear Ektar Cover offers optimum chemical resistance and strength and is environmentally sealed to prevent fogging or entry of contaminants.
- Careful material selection provides patented indicator a rated life of minimum 1,000,000 cycles.
- Materials of construction selected to excel in high vibration, corrosive and dirty environments, either indoors or outdoors.
- Indicator is fully adjustable to any valve or actuator
- Internal Switches and terminal block are labeled for easier installation.
- The industry’s only “true” visual valve position indicator available for multi-port valves, adjustable to match the actual physical flow pattern of the valve.
- ”Flat cover” version is available without an indicator for areas with tight space requirements.
- See datasheet for additional details.
Note: These rotary limit switches are compatible with pneumatic actuators from ABZ Valves, Quadrant and Sharpe Valves.
