Material: Carbon steel
Finish: Plain or Hot-Dip Galvanized
Service: Trapeze assembly is to be suspended by two rods with Fig. 60 washer plates and is designed for top loading exclusively.
Ordering: Specify size number, figure number, name, finish, C to C dimension and hole size “H”. If holes “J” or hole “D” are required, also specify hole size and dimensions “K” and “M” or “B”.
Note: Larger C to C dimensions are available upon request.
